Heavy sand pump drains every swamp

However, “water” can hardly be taken literally: Declared as a "heavy sand pump", the GPN 837 is intended for use wherever considerable amounts of solid matter are involved - for example in gravel pits or where sand, sludge, slurry and preferably also Bentonite are involved. For this purpose, the engineers have designed the pump with a solid construction. At 150 litres per second, hard rocks up to 30 mm in size can pass through the pump with ease. The agitator at the suction opening mixes mud and water so that it becomes more fluid.

The pump with a dry weight of 815 kg and a height of roughly one meter, is driven by an electric motor with 37 kW (400 V). The GPN 837 pumps vertically up to 24 metres. When submerged, it is pressure-resistant to a depth of 30 metres. The water is diverted in a spiral around the pump: a trick to counter the high abrasive effect of the pumped medium. The impeller and suction plate are also made of chrome cast iron, the housing of grey cast iron GG 20. For critical elements such as the double inside mechanical seal, the manufacturer uses even silicon carbide - a material nearly as hard as diamond. Tsurumi´s innovative oil lifter, which lubricates the pump shaft in any position reliably by centrifugal force, is also installed.

Like everything else in the Japanese manufacturer's product range, the new GPN is available from stock in Düsseldorf or Antwerp and is shipped to the customer within 24 hours. The model can also be rented for temporary needs.
